We at JOIN PACK MACHINES lay a lot of stress on providing Timely Preventive & Breakdown Service for our machines. According to our business philosophy, this aspect of our Operation is THE Most Important Part of our day-to-day working. Our Sales & Service Engineers are technically prepared in training your Personnel in operating these Machines and also in basic trouble-shooting & preventive maintenance

Box Strapping Machines Automatic Strapping machines

Narrow Strap (A-66)

NARROW STRAP AUTOMATIC STRAPPING MACHINE

SCOPE OF APPLICATION

NEWSPAPER BUNDLING, MAGAZINES, BOOKS, LIGHT WEIGHT CARTONS / SMALL SIZE CARTONS

FEATURES
Automatic strap feeding	Electronic tension control
Automatic loop ejecting system	One motor driving system
Advanced PLC system	Power save auto shut-off
Ball switch control

OPTIONS
Foot pedal switch control	Strap empty indicator
Press unit	Belt drive
Other customized feature

SPECIFICATIONS
Strapping speed :	1.6sec / cycle (60HZ)
-	36straps per min. (60Hz)
Tension	1-75kg
Sealing method	instant electric heating-30sec
Strap width	5, 6mm p.p strap
Packing size	Mini 80mm (W) x 35mm (H)
Strap dispenser	200mm x 180mm (8" x 7")
	230mm x 180mm (9" x 7")
Reel outside dia	480mm
Table height	825mm from ground level
Power connection	AC 110/220/230V, 50/60HZ, 1phase
Power consumption	0.8KVA
Layout dimension	900mm (W) x 620mm (D) x 1375mm (H)
Identification	H-height, W-width, D-depth
*Specification subject to change without prior notice

VARIOUS ARCH SIZE AVAILABLE:

H/W	450	650	850	1050
300
450		Standard
600
800
